Water Pressure Pump – HTP 22
Original price was: ₹3,888.00.₹3,500.00Current price is: ₹3,500.00.
Engineered for high-pressure performance and industrial-grade durability, the Water Pressure Pump- HTP 22 is the ultimate solution for agricultural spraying, dairy farm washing, and commercial vehicle cleaning. Featuring robust cast-iron construction and precision stainless-steel plungers, this Horizontal Triplex Plunger (HTP) pump delivers an ultra-powerful, continuous water throw with maximum power efficiency.
Ideal Applications: Small-scale dairy farm floor & cattle washing, standard orchards, commercial car washing, and residential pressure cleaning.
Key Features
- Triplex Plunger Technology: Three precision-engineered plungers work in tandem to deliver an ultra-stable, high-pressure water stream with minimal pulsation.Â
- Heavy-Duty Cast Iron Housing: Rugged, industrial-grade pump body protects internal components and ensures a prolonged operational lifespan under extreme workloads.Â
- Flexible Prime Mover Coupling: Standard pulley design allows easy compatibility with both single/three-phase electric motors and portable petrol/diesel engines.Â
- Stainless Steel Plungers & Valves: High-tensile pistons and corrosion-resistant valves prevent chemical wear from pesticides, fertilizers, and hard water.Â
- Integrated Pressure Control Valve: Features an easily adjustable pressure regulating knob and a built-in bypass system to prevent system overloading.Â
Low Maintenance Design: Large oil reservoir crankcase ensures smooth mechanical movement, low heat generation, and highly simplified routine oil changes.
Take your cleaning and spraying operations to the next level with the Water Pressure Pump- HTP 22. Designed to meet the demanding needs of modern farmers and service station owners, this pump utilizes an advanced three-plunger (triplex) system that drastically reduces pressure fluctuations, ensuring a remarkably smooth, high-velocity water output.Â
Built with a heavy-duty, corrosion-resistant cast iron body and fitted with premium alloy pistons, it is crafted to endure long working hours in harsh, dusty, or humid environments. It can be effortlessly coupled with either an electric motor or a petrol/diesel engine via a belt-driven pulley system. This standard commercial variant provides rugged reliability and intense hydraulic pressure, making it ideal for small-scale dairy farm floors, cattle washing, and standard commercial car washing decks.
| Weight | 11.5 kg |
|---|---|
| Dimensions | 48 × 40 × 43 cm |
| Pump Type | Horizontal Triplex Plunger (HTP) |
| Suction Capacity (Output) | 15 to 22 Liters/Min |
| Normal Working Pressure | 10 to 40 kg/cm² (150-600 PSI) |
| Maximum Pressure | Up to 45 kg/cm² |
| Required Electric Motor | 1.0 HP to 2.0 HP |
| Required Engine Power | 3.0 HP to 5.0 HP (Petrol/Diesel) |
| Standard Pump Speed | 800 – 1000 RPM |
| Number of Plungers | (Stainless Steel / Alloy) |
By purchasing from Cow Tools, you agree to the following terms:
By purchasing from Cow Tools, you agree to the following terms:
- 3-Day Replacement Policy: Replacement is available only for manufacturing defects, damaged products, or wrong items delivered. Customers must report the issue within 3 days of delivery with photo/video proof.
- Dispatch & Delivery: Dispatch time is 2 to 3 working days, with an estimated delivery timeline of 5 to 8 working days.
- Transportation Delay Disclaimer: Delivery timelines may vary due to transport or courier delays. Cow Tools is not responsible for delays caused by third-party transportation services.
- Payment Policy: Full payment must be completed before order dispatch.
- Warranty: Warranty covers manufacturing defects only and does not cover damage caused by misuse, improper handling, or unauthorized repairs.
- Order Cancellation: Orders cannot be cancelled once they have been dispatched.
By placing an order, you accept all the above terms and policies.
